Weld Symbol

Collapse
X

  • Filter
  • Time
  • Show
Clear All
new posts

  • Weld Symbol

    Can someone decipher this symbol, I don't believe it's correct
    Click image for larger version

Name:	Weld Symbol.jpg
Views:	1
Size:	52.2 KB
ID:	533815
    Richard
    West coast of Florida
    Website

  • #2
    Originally posted by Ltbadd View Post
    Can someone decipher this symbol, I don't believe it's correct
    [ATTACH]35177[/ATTACH]
    are you talking the 1/16-3/16 fillet..??


    A basic welding symbols tutorial and their definitions for reading plans or blueprints.
    Last edited by H80N; 04-15-2015, 06:08 PM.
    .

    *******************************************
    The more you know, The better you know, How little you know

    “The bitterness of poor quality remains long after the sweetness of low price is forgotten”

    Buy the best tools you can afford.. Learn to use them to the best of your ability.. and take care of them...

    My Blue Stuff:
    Dynasty 350DX Tigrunner
    Dynasty 200DX
    Millermatic 350P w/25ft Alumapro & 30A
    Millermatic 200

    TONS of Non-Blue Equip, plus CNC Mill, Lathes & a Plasmacam w/ PowerMax-1000

    Comment


    • #3
      Originally posted by H80N View Post
      are you talking the 1/16-3/16 fillet..??


      http://www.wcwelding.com/welding-symbols.html
      Yes, are you saying it's giving the size of the fillet? This is a weld on a bolt, so I'd tend to believe they want an all around symbol. If it's the size of the fillet then it should be located to the left of the fillet symbol...?

      Also the drawing doesn't show an all around weld, if we're trusting the drawing
      Richard
      West coast of Florida
      Website

      Comment


      • #4
        Originally posted by Ltbadd View Post
        Yes, are you saying it's giving the size of the fillet? This is a weld on a bolt, so I'd tend to believe they want an all around symbol. If it's the size of the fillet then it should be located to the left of the fillet symbol...?

        Also the drawing doesn't show an all around weld, if we're trusting the drawing
        It looks like fillet width & tolerance to me...

        but I am not a production guy..

        can you get clarification from the customer??
        .

        *******************************************
        The more you know, The better you know, How little you know

        “The bitterness of poor quality remains long after the sweetness of low price is forgotten”

        Buy the best tools you can afford.. Learn to use them to the best of your ability.. and take care of them...

        My Blue Stuff:
        Dynasty 350DX Tigrunner
        Dynasty 200DX
        Millermatic 350P w/25ft Alumapro & 30A
        Millermatic 200

        TONS of Non-Blue Equip, plus CNC Mill, Lathes & a Plasmacam w/ PowerMax-1000

        Comment


        • #5
          I think the dwg. is wrong. I would clarify with who ever spec'd it.
          MM250
          Trailblazer 250g
          22a feeder
          Lincoln ac/dc 225
          Victor O/A
          MM200 black face
          Whitney 30 ton hydraulic punch
          Lown 1/8x 36" power roller
          Arco roto-phase model M
          Vectrax 7x12 band saw
          Miller spectrum 875
          30a spoolgun w/wc-24
          Syncrowave 250
          RCCS-14

          Comment


          • #6
            Originally posted by MMW View Post
            I think the dwg. is wrong. I would clarify with who ever spec'd it.
            H8ON and MMW I agree, just wanted someone else's eyes on this
            Richard
            West coast of Florida
            Website

            Comment


            • #7
              Weld Symbol

              Wrong !
              the fillet weld symbol should have been on top of the line , drawing f.. up!

              Comment


              • #8
                Weld Symbol

                "draft person f..up"

                Comment


                • #9
                  The drawing is showing a bolt that's used to lock one shaft to another. The shafts are also key'd together so the bolt is just some added help for the key.
                  They want 1/16" of weld at 3/16" pitch all around the nut that the bolt screws into. That probably works out to 1/16" of weld on each face (flat part) of the nut.
                  Last edited by snoeproe; 04-16-2015, 05:36 AM.
                  Lincoln Idealarc 250
                  Miller Bobcat 250
                  Thermal Arc Hefty 2 feeder
                  Thermal Dynamics Cutmaster 52
                  Torchmate CNC table

                  Comment


                  • #10
                    Originally posted by snoeproe View Post
                    The drawing is showing a bolt that's used to lock one shaft to another. The shafts are also key'd together so the bolt is just some added help for the key.
                    They want 1/16" of weld at 3/16" pitch all around the nut that the bolt screws into. That probably works out to 1/16" of weld on each face (flat part) of the nut.
                    If this is the case then the dwg. is really wrong as it doesn't even show or mention a nut. No matter what the draftsman wants to show he needs to clarify it so someone can build this to what he wants.

                    I have seen this numerous times & a phone call can usually clear things up. Try to talk to the draftsman & not the purchasing agent though.

                    EDIT - Looking at the dwg. again, I think they clearly want the bolt welded as they give a 5/16" reference for the height from the od of the shaft to the top of the bolt head. But we are only seeing one view of the dwg.
                    Last edited by MMW; 04-16-2015, 05:48 AM.
                    MM250
                    Trailblazer 250g
                    22a feeder
                    Lincoln ac/dc 225
                    Victor O/A
                    MM200 black face
                    Whitney 30 ton hydraulic punch
                    Lown 1/8x 36" power roller
                    Arco roto-phase model M
                    Vectrax 7x12 band saw
                    Miller spectrum 875
                    30a spoolgun w/wc-24
                    Syncrowave 250
                    RCCS-14

                    Comment


                    • #11
                      Originally posted by MMW View Post
                      If this is the case then the dwg. is really wrong as it doesn't even show or mention a nut. No matter what the draftsman wants to show he needs to clarify it so someone can build this to what he wants.

                      I have seen this numerous times & a phone call can usually clear things up. Try to talk to the draftsman & not the purchasing agent though.

                      EDIT - Looking at the dwg. again, I think they clearly want the bolt welded as they give a 5/16" reference for the height from the od of the shaft to the top of the bolt head. But we are only seeing one view of the dwg.
                      Correct, the bolt threads into the part, no nut. If I understand correctly, if 1/16" is the fillet size it should be located to the left of the fillet symbol, to the right would be information concerning the length and center to center spacing

                      I'm sure most who have been in the trade has dealt with interpreting symbols drawn by someone who doesn't understand weld symbols but perhaps also someone not understanding the correct way a part should be welded.
                      Richard
                      West coast of Florida
                      Website

                      Comment


                      • #12
                        On anything that's continuously circular, there is no "weld all around" symbol. Weld all around is your only option unless they call out an intermitent weld sequence.

                        If you're getting high centered over a goofy weld symbol on a drawing, then get used to it. It happens about 3.78 million times per day. Detailers punch out work as fast as they can and make many errors. That's what "as builts" are for : )

                        You don't clarify thru the "draftsman", actually called a detailer, you clarify thru the EOR (Engineer of Record).
                        The EOR has ultimate responsibility for all design weather it's drawn up by a EIT, Detailer, the Coffee Fetcher or a Drunk on a Napkin.

                        EOR's in my experience, are quite happy to clarify all welding details to the DRFMTW's (Dudes Responsible For Making The Welds). They will always send written (usually emailed) clarification for liability (theirs and yours, mainly theirs) purposes.

                        The EOR who stamped the drawings assumes ALL responsibility for the entire design even tho some or most/all of the calc work is done by others. He/She WILL answer your questions thoroughly in short order. Otherwise He/She faces delay of production charges.

                        Most are, again in my experience, very helpful, patient and understanding of questions from the sharp end.

                        Just don't expect to receive drawings with all proper weld call outs. Not gonna happen often.

                        J
                        Some days you eat the bear. And some days the bear eats you.

                        Comment


                        • #13
                          Originally posted by JTMcC View Post
                          On anything that's continuously circular, there is no "weld all around" symbol. Weld all around is your only option unless they call out an intermitent weld sequence.

                          If you're getting high centered over a goofy weld symbol on a drawing, then get used to it. It happens about 3.78 million times per day. Detailers punch out work as fast as they can and make many errors. That's what "as builts" are for : )

                          You don't clarify thru the "draftsman", actually called a detailer, you clarify thru the EOR (Engineer of Record).
                          The EOR has ultimate responsibility for all design weather it's drawn up by a EIT, Detailer, the Coffee Fetcher or a Drunk on a Napkin.

                          EOR's in my experience, are quite happy to clarify all welding details to the DRFMTW's (Dudes Responsible For Making The Welds). They will always send written (usually emailed) clarification for liability (theirs and yours, mainly theirs) purposes.

                          The EOR who stamped the drawings assumes ALL responsibility for the entire design even tho some or most/all of the calc work is done by others. He/She WILL answer your questions thoroughly in short order. Otherwise He/She faces delay of production charges.

                          Most are, again in my experience, very helpful, patient and understanding of questions from the sharp end.

                          Just don't expect to receive drawings with all proper weld call outs. Not gonna happen often.

                          J
                          Thanks for the informative response.

                          I felt fairly confident the symbol was wrong, as I don't claim to be an expert in this regard. My intent for this post was to get feedback and I was not disappointed. I could have easily gone to my customer about this, however I thought someone on the forum could confirm what I already believed, and in the process I hope others have learned something as I have with many of the threads on this forum. My thanks to all who responded
